Sena Pergola

Curved pergola utilizing 102mm x 102mm (4”x 4”) aluminum beams and columns.  Components are pre-finished in premium polyester powder coating and mechanically fastened using stainless steel hardware. Designed as single or modular, in stand-alone or attached configurations Sena is made to your specifications.  Recommended 4267  (168”) minimum inside radius and maximum 5588 (220") outer span between columns.

Typical height: 2438 to 3000 (96” to 118”)

Roof Options - Purlins

Vertically Oriented

Underhanging Beams

Vertically Oriented

Overhanging Beams

Stur Design Pergola Purlins

Purlin End Styles

Typical Purlin Profiles - custom size, styles and materials available
Aluminum purlins available with wood grain finishes

Cedar and other species as specified. Custom sizing available.

We do not offer Ipe.

Roof Options

Laser Cut Aluminium

Custom Designs

Solid - Polycarbonate or Aluminum Panels

Retractable Fabric

Alone or in Combination

Power, Heat and Light

All sturdesign shade products can be manufactured to accommodate internal wiring for power supply. We can prepare our products to receive your specified for USB CHARGING RECEPTACLES, INFRARED HEATING and LED LIGHTING (strip, marker, down lighting, spot lighting). See Accessories for more details and contact sturdesign for options and specifications.

Privacy / Wind Mitigation (for independent screens see here)
Installation

Sturdesign's pre-fabricated manufacturing process simplifies onsite assembly and installation. We provide step by step instructions and we supply the tooling heads to engage any optional tamper proof stainless steel hardware. Typical bolt-down installation utilizes wedge anchors or embedded rods, custom site-specific solutions are available.

Optional Mounting Plate Cover
